THM – C180 series – Proportional Valves

Description

THM – C180 series – Proportional Valves

• C180 series controller/IO module products have flexible port reuse, compact design, and support up to 2-channel CAN2.0B bus Line communication, equipped with ARM Cortex™ M7 core high-speed processor, built-in floating point operation unit FPU and DSP functions, computational performance can be greatly improved, providing users with greater freedom. The product has extremely high cost performance and is widely used in vehicle-mounted aerial work machinery, Small control systems and automation control fields such as truck-mounted cranes, aerial work machinery, and logistics handling machinery.
• C180 series controller/IO module can work at -40~85°C temperature, has IP66 protection level, and can be \ used in extremely harsh climate environments.
• The C180 series controller/IO module allows users to remotely upgrade applications and firmware via OTA, which facilitates system maintenance and reduces production costs. The total cost of all stages of the product life cycle) to accelerate your digital transformation.
• C180S controller adopts C language or CODESYS V3.5 for application development, powerful API function interface
• The interface and supporting tool chain, detailed instructions and demo program can speed up the application development process.
• C180M series IO modules adopt the standard CANopen protocol. No programming is required. All can be used through simple configuration. Function, the supporting eds file can be flexibly loaded into the controller programmed using CODESYS, which is simple and easy to use

Product features

• 32bit high-performance processor, 200 MHz frequency
• High-speed SPI interface ferroelectric memory chip (FRAM), 1 billion erase lifespan
• 2-way CAN interface, maximum speed up to 1Mbps
• Support remote OTA upgrade, and differential upgrade can be customized according to needs
• The product is highly integrated and flexible in reuse, with a total of 30 IO ports, which can be configured as up to 14 outputs and 26 inputs.
• 4-channel 2.5A high-side PWM/DO output ports support constant current output to meet closed-loop control requirements
• Up to 4 channels of 4.0A high-side DO output ports, all with diagnostic functions
• Up to 10 channels of 2.5A high-side DO output ports, all with diagnostic functions
• 8 channels of 4..20mA / 0…5V / DIH input ports, each channel can be configured independently to facilitate the processing of voltage and current signals.
• 2 channels of 10~30KΩ/DIL input ports, each channel can be configured independently to facilitate the collection of resistance signals
• 2 PI/DIH input ports, frequency acquisition signal range 1~10KHz, signal threshold voltage can be adjusted through software
• 2 channels of DIH/DIL switch input ports, each channel can be configured independently
• 2 channels of 0…32V/DIH input ports, configurable through software
• The software is developed using C language or CODESYS V3.5, and can support static code testing, software version management and other functions
