Hydraulic Pumps

Top 10 Different Types of Hydraulic Pumps Used in Industries

Hydraulic pumps are essential components in various industrial applications, converting mechanical energy into hydraulic energy to power machinery and equipment.

Here are brief introductions of the top 10 different types of hydraulic pumps used in industries and their specifications.

  1. Gear Pumps

Gear pumps are the most common type of hydraulic pump, characterized by their simple design and reliability. They consist of two meshing gears that rotate to create a negative pressure that draws fluid into the pump chamber.

Technical Details:

  • Types: External gear pumps and internal gear pumps
  • Pressure Range: Up to 200 bar
  • Flow Rate: Typically 4-1200 LPM

Uses:

  • Lubrication Systems: Provide a steady flow of lubricants to machinery components.
  • Chemical Processing: Handle the transfer of chemicals with consistent flow rates.
  • Fuel Transfer: Used in fueling systems for efficient and safe transfer of fuels.
  1. Piston Pumps

Piston pumps are known for their high efficiency and capability to operate at very high pressures. They use a series of pistons driven by a cam to supply the hydraulic fluid.

Technical Details:

  • Types: Axial piston pumps and radial piston pumps
  • Pressure Range: Up to 450 bar
  • Flow Rate: Variable flow depending on design

Uses:

  • Hydraulic Presses: Deliver the high pressure needed for pressing operations.
  • Industrial Machinery: Power various types of heavy industrial equipment.
  • Marine Applications: Used in steering and other hydraulic systems on ships.

3. Axial Piston Pumps

Axial piston pumps have multiple pistons arranged in a circular array within a cylinder block. The pistons move parallel to the drive shaft, providing high-pressure output.

Technical Details:

  • Types: Swashplate and bent axis designs
  • Pressure Range: Up to 500 bar
  • Flow Rate: 38-1200 LPM

Uses:

  • Aerospace: Hydraulic systems in aircraft for control surfaces and landing gear.
  • Construction Equipment: High-performance hydraulics for excavators and cranes.
  • Oil and Gas Extraction: Power hydraulic fracturing and other extraction equipment.
  1. Radial Piston Pumps

Radial piston pumps have pistons arranged radially in a cylinder block. These pumps are highly efficient and can handle very high pressures.

Technical Details:

  • Pressure Range: Up to 550 bar
  • Flow Rate: 4-200 LPM

Uses:

  • Machine Tools: Precision control for CNC machines and other tools.
  • Industrial Automation: High-pressure systems for automated manufacturing processes.
  • Mining Equipment: Robust and reliable pumps for heavy-duty mining operations.
  1. Orbital (Gerotor) Pumps

Orbital pumps, also known as gerotor pumps, use an internal rotor that meshes with an external rotor. They are known for their compact design and steady flow.

Technical Details:

  • Pressure Range: Up to 200 bar
  • Flow Rate: 0.4-120 LPM

Uses:

  • Hydraulic Motors: Provide smooth and consistent power for hydraulic motors.
  • Power Steering Systems: Compact and efficient for automotive applications.
  • Low-Pressure Applications: Ideal for applications requiring steady flow at low pressures.
  1. Vane Pumps

Vane pumps feature vanes mounted on a rotor that rotates inside a cavity. As the rotor turns, the vanes slide in and out, creating a variable volume that moves fluid through the pump.

Technical Details:

  • Types: Balanced vane pumps and Unbalanced vane pumps
  • Pressure Range: Up to 150 bar
  • Flow Rate: 38-700 LPM

Uses:

  • Mobile Hydraulics: Common in construction machinery like excavators and loaders.
  • Automotive Power Steering: Provides the hydraulic pressure needed for power steering systems.
  • Plastic Injection Molding Machines: Ensures precise control of hydraulic fluid for molding processes.

   7 . Screw Pumps

Screw pumps use two or more intermeshing screws to move fluid through the pump. They are ideal for handling large volumes of fluid with low pulsation and noise.

Technical Details:

  • Types: Single screw, twin screw, and triple screw designs
  • Pressure Range: Up to 100 bar
  • Flow Rate: 20-2000 LPM

Uses:

  • Hydraulic Elevators: Smooth and quiet operation for elevator systems.
  • Oil Transfer Systems: Efficiently move oil in pipelines and processing plants.
  • Food and Beverage Industry: Sanitary design for handling food-grade fluids.
  1. Centrifugal Pumps:

Centrifugal pumps use a rotating impeller to move fluid through the pump. They are widely used for transferring fluids in various industries due to their simplicity and effectiveness.

Technical Details:

  • Pressure Range: Up to 20 bar
  • Flow Rate: 38-38000 LPM

Uses:

  • Water Supply Systems: Common in municipal and industrial water supply systems.
  • HVAC Systems: Circulate water in heating and cooling systems.
  • Fire Protection Systems: Provide high-volume water flow for fire suppression.
  1. Peristaltic Pumps

Peristaltic pumps use a rotor to compress a flexible tube, creating a peristaltic motion that moves fluid through the pump. These pumps are excellent for handling abrasive or viscous fluids.

Technical Details:

  • Pressure Range: Up to 15 bar
  • Flow Rate: 0.4-400 LPM

Uses:

  • Chemical Dosing: Precise delivery of chemicals in water treatment plants.
  • Water Treatment: Handling sludge and other viscous fluids.
  • Pharmaceutical Industry: Sterile transfer of medications and other fluids.
  1. Diaphragm Pumps

Diaphragm pumps use a diaphragm driven by a mechanical or hydraulic actuator to move fluid. They are suitable for handling corrosive and viscous fluids.

Technical Details:

  • Pressure Range: Up to 80 bar
  • Flow Rate: 0.4-400 LPM

Uses:

  • Chemical Processing: Safe handling of aggressive chemicals.
  • Paint Spraying: Provides consistent pressure for paint application.
  • Sewage and Sludge Handling: Efficiently moves thick, abrasive materials.

Conclusion

Hydraulic pumps are vital in numerous industrial applications, each type offering unique advantages and used to specific applications. Gear pumps and vane pumps are suitable for low to medium pressure applications, while piston and axial piston pumps excel in high-pressure environments. Screw, peristaltic, and diaphragm pumps are excellent for handling specific fluid characteristics such as viscosity and abrasiveness. Orbital pumps are preferred for compact and steady flow requirements, and centrifugal pumps are ideal for large volume transfers. Understanding the specific use cases and technical details of each type helps in selecting the right pump for optimal performance and reliability in industrial operations.
